DOORS FOR CLOSED COMPARTMENTS

Ultra doors are designed to enclose Ultra shelves, drawers and case compartments and to shut off floor-level storage.

Doors for enclosed compartments in the van

There are three different types of door:

lift-up doors
top-pivot doors
lift-and-rotate doors

All types are modular in width and height and can be combined as needed.

LIFT-UP DOORS

12_A lift-up door with a parallelogram action hinge system

Doors of this type open upwards and come to rest parallel to the racking above. Opening them therefore requires very little space in the centre of the van. Lift-up doors are mounted on a parallelogram opening system with two gas springs and an integrated synchronisation tube. The opening mechanism is completely maintenance-free. These doors measure 324 mm in height and can be installed directly at floor level, in conjunction withlight-duty or heavy-duty profiles or above most Ultra horizontal elements, to suit the user’s needs.

LIFT-UP DOORS WITH LOCKS

A van racking system with a lockable lift-up door

For greater security, lift-up doors are also available with a lock. The locking mechanism operates two internal latches that secure the door at the left and right sides.

TOP-PIVOT DOORS

Top-pivot doors are mounted on gas spring hinges and rotate upwards and outwards, coming to rest at an oblique angle to the racking. They are available in two heights, 180 and 324 mm, and in various widths from 507 to 1521 mm.

LIFT-AND-ROTATE DOORS

A lift-and-rotate door for enclosing the space around the wheel arch

This type of door opens downwards and comes to rest at the same level as the shelf to which it is fixed. The special lift-and-rotate hinges are protected by a Syncro System patent. These doors provide unrestricted access to the compartment behind. They feature a recessed handle and have no protruding parts. Lift-and-rotate doors are made entirely from steel and are completely maintenance-free. They can be installed at any height in a column of racking but must be above another element. They come in heights 108 and 252 mm, with or without profile.

COMBINING DOORS WITH OTHER ELEMENTS

Ultra doors can be fitted in front of:

THE VAN RACKING SPECIALISTS

Lift-up, top-pivot and lift-and-rotate doors can enclose open shelves and compartments, improving tidiness and security by hiding items from prying eyes.
