The racking system presented on this page was installed by Syncro System in a Mercedes Vito operated by a company that installs and services cogeneration systems
. The vehicle is thoroughly lined, has racking on both sides and is equipped with accessories to make it completely functional.
If you’d like to learn more about this racking solution, carry on reading.
If you want to see other racking systems for the Mercedes Vito, start here.
On this page you can find a racking system for a cogeneration service in a Fiat Doblò; and here another racking system in a Ford Custom.
As always when we set out to install a racking system in a working van, protecting the interior is the first step and has to be done before any item of racking is put in place.
Covering the van’s delicate body panels with robust, custom-made lining panels not only extends the vehicle’s life but saves you costly bodywork repair bills too. The owner of this van opted for a complete protective lining system.
The floor is covered by a plywood floor liner with a rubber-coated surface that provides an excellent grip.
The bulkhead is lined from floor to roof, again in birch plywood, but this time with a marble-look resin surface.
The walls and doors are lined with painted steel panels.
The left side
of this Vito for servicing cogeneration systems is equipped with racking for its entire length. Every inch of space has been fully exploited thanks to the way in which Syncro Ultra
racking can follow the contours of the van walls while remaining perfectly vertical at the front.
At floor level, there are three compartments for different purposes: the first is fitted with a lift-up door
to form an enclosed space; the second is fitted with a retaining strap to form a tool case compartment
; the third houses a vertical oilless compressor
that provides a compressed air supply when the van is away from base.
Higher up are three configurable shelves
with rear panels, non-slip mats and metal space dividers for creating separate compartments if needed, and a series of metal drawers with automatic retaining mechanisms.
The next level consists of shelves for removable containers
, complete with adapters to guide the containers in and out and hold them firmly in place. At the top, the racking finishes in two top trays.
The right side
of the Vito is also fully equipped, leaving only the side door free.
The compartment at floor level is equipped with a strap and hook system
to keep cargo and material securely in place. Above this is a configurable shelf that runs the full length of the racking and, further up again, a set of pull-out trays with metal cases. These trays slide in and out just like drawers while the cases provide a great way to carry power tools and small parts.
Apart from two small shelves to hold frequently needed items like insulating tape and scissors, the racking on this side is completed by two cabinets of pull-out containers in transparent plastic.
This cogeneration service’s Vito is equipped with a series of accessories to maximise functionality.
At the rear doors:
a handwash kit comprising a mounting frame and a large plastic jerry can with a tap
a robust fold-away table made from marble-look plywood, installed so that it opens parallel with the floor
On the racking side panels:
a bar rack with a strap;
a paper roll holder
two metal pockets
a set of electrical power sockets connected to the van’s electrical system;
a fold-away vice bench complete with metal vice
On the floor:
cut-to-size rails for use with hooks, lashing straps and cargo retaining bars.
